Mainboard, ASUS, AMD B650, SAM5, Micro-ATX, Memory DDR5, Memory slots 4, 2xPCI-Express 4.0 16x, 2xM.2, 1xVGA, 1xHDMI, 1xDisplay

Mainboard, ASUS, AMD B650, SAM5, Micro-ATX, Memory DDR5, Memory slots 4, 2xPCI-Express 4.0 16x, 2xM.2, 1xVGA, 1xHDMI, 1xDisplay

Name: Mainboard, ASUS, AMD B650, SAM5, Micro-ATX, Memory DDR5, Memory slots 4, 2xPCI-Express 4.0 16x, 2xM.2, 1xVGA, 1xHDMI, 1xDisplay
Brand: ASUS
SKU: PRIME B650M-A II-CSM
Price: 132.16 EUR
Availability: InStock

Gamintojas: ASUS

Kodas PRIME B650M-A II-CSM

Yra sandėlyje

132,16 €

Su mokesčiais

Pristatoma 1 - 3 darbo dienos

AMD B650 , micro ATX , Audio 7.1 channels , CPU AMD , Socket Socket AM5 , Series AMD Ryzen 7000 Series , Supported memory types DDR5-SDRAM , 4xNumber of memory slots , Memory slots type DIMM , Supported storage drive interfaces M.2,SATA III , 4xUSB 2.0 ports quantity , 2xUSB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity , 2xUSB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity , 1xEthernet LAN (RJ-45) ports , 1xHDMI ports quantity

Prekės informacija
Atsiliepimai (0)

SUMMARY: ASUS PRIME B650M-A II-CSM. PROCESSOR MANUFACTURER: AMD, PROCESSOR SOCKET: SOCKET AM5, COMPATIBLE PROCESSOR SERIES: AMD RYZEN 7000 SERIES. SUPPORTED MEMORY TYPES: DDR5-SDRAM, MAXIMUM INTERNAL MEMORY: 128 GB, MEMORY SLOTS TYPE: DIMM. SUPPORTED STORAGE DRIVE
CNCODE: 84733020
CATEGORY CODE: MBA
UNIT BOX LENGTH: 0.28
UNIT BOX HEIGHT: 0.07
UNIT BOX WIDTH: 0.275
PRODUCT COLOUR: BLACK
DEPTH, MM: 244
WIDTH, MM: 244
UNITS PER SHIPPING BOX: 10
UNIT CALCULATED VOLUME, CUBM: 0.006187
UNIT CALCULATED WEIGHT, KG: 1.35
CABLES INCLUDED: SATA
ATX POWER CONNECTOR (24-PIN): YES
USB 3.2 GEN 1 (3.1 GEN 1) TYPE-A PORTS QUANTITY: 2
NUMBER OF HDDS SUPPORTED: 4
MODEL: PRIME B650M-A II-CSM
USB 3.2 GEN 2 (3.1 GEN 2) TYPE-A PORTS QUANTITY: 2
NUMBER OF STORAGE DRIVES SUPPORTED: 6
USB 2.0 PORTS QUANTITY: 4
PROCESSOR MANUFACTURER: AMD
WI-FI: No
ON-BOARD GRAPHICS CARD: NO
MAXIMUM INTERNAL MEMORY, GB: 128
HDMI PORTS QUANTITY: 1
ETHERNET LAN: YES
ETHERNET LAN (RJ-45) PORTS: 1
HEADPHONE OUTPUTS: 1
MICROPHONE IN: YES
AUDIO OUTPUT CHANNELS, CHANNELS: 7.1
MOTHERBOARD CHIPSET: AMD B650
LINE-IN: YES
PS/2 PORTS QUANTITY: 1
MEMORY CHANNELS: DUAL-CHANNEL
DISPLAYPORTS QUANTITY: 1
MEMORY SLOTS TYPE: DIMM
PROCESSOR SOCKET: SOCKET AM5
COMPONENT FOR: PC
WINDOWS OPERATING SYSTEMS SUPPORTED: WINDOWS 10 X64/WINDOWS 11
ETHERNET INTERFACE TYPE: 2.5 GIGABIT ETHERNET
PARALLEL PROCESSING TECHNOLOGY SUPPORT: NOT SUPPORTED
RAID SUPPORT: YES
COMPATIBLE PROCESSOR SERIES: AMD RYZEN 7000 SERIES
SUPPORTED PROCESSOR SOCKETS: SOCKET AM5
MOTHERBOARD CHIPSET FAMILY: AMD
MOTHERBOARD FORM FACTOR: MICRO ATX
ECC СOMPATIBILITY: ECC & NON-ECC
NUMBER OF MEMORY SLOTS: 4
SUPPORTED MEMORY TYPES: DDR5-SDRAM
UNBUFFERED MEMORY: YES
SUPPORTED STORAGE DRIVE INTERFACES: M.2,SATA III
SUPPORTED STORAGE DRIVE TYPES: HDD & SSD
12V POWER CONNECTOR: YES
CPU FAN CONNECTOR: YES
FRONT PANEL AUDIO CONNECTOR: YES
FRONT PANEL CONNECTOR: YES
NUMBER OF CHASSIS FAN CONNECTORS: 3
RGB LED PIN HEADER: YES
USB 2.0 CONNECTORS: 2
USB 3.2 GEN 1 (3.1 GEN 1) CONNECTORS: 2
NUMBER OF SATA III CONNECTORS: 4
NUMBER OF M.2 (M) SLOTS: 2
BIOS MEMORY SIZE, MBIT: 256
BIOS TYPE: UEFI AMI
SUPPORTED MEMORY CLOCK SPEED (MAX), MHZ: 6400
CLEAR CMOS BUTTON: YES
SUPPORTED MEMORY CLOCK SPEEDS, MHZ: 4800/5000/5200/5400/5600/5800/6000/6200/6400
NUMBER OF COM CONNECTORS: 1
TPM CONNECTOR: YES
PCI EXPRESS X16 (GEN 3.X) SLOTS: 3
AUDIO CONNECTOR: YES
