Switch, TELTONIKA, SWM282000200, Switch type Managed, Switch layer L2, 24xRJ-45 ports, Power over Ethernet (PoE) Yes, 24xPower

Name: Switch, TELTONIKA, SWM282000200, Switch type Managed, Switch layer L2, 24xRJ-45 ports, Power over Ethernet (PoE) Yes, 24xPower
Brand: TELTONIKA
SKU: SWM282
Price: 337.58 EUR
Availability: InStock

Gamintojas: TELTONIKA

Kodas SWM282

Yra sandėlyje

337,58 €

Su mokesčiais

Pristatoma 1 - 3 darbo dienos

SWM282000200 , Type Managed , Switch layer L2+ , Quality of Service (QoS) support Yes , Web-based management Yes , 24xBasic switching RJ-45 Ethernet ports quantity , Basic switching RJ-45 Ethernet ports type Gigabit Ethernet (10/100/1000) , 4xSFP module slots quantity , Port mirroring Yes , Switching capacity 56 Gbit/s , Forwarding rate 83.33 Mpps , Rack mounting Yes , Product colour Black , Power source AC , Power over Ethernet (PoE) Yes , 24xPower over Ethernet plus (PoE+) ports quantity , Power over Ethernet (PoE) power per port 30 W , Total Power over Ethernet (PoE) budget 300 W , Width 483 mm , Depth 234 mm , Height 44 mm , Weight 2291 g

Prekės informacija
Atsiliepimai (0)

SUMMARY: TELTONIKA SWM282. SWITCH TYPE: MANAGED, SWITCH LAYER: L2+. BASIC SWITCHING RJ-45 ETHERNET PORTS TYPE: GIGABIT ETHERNET (10/100/1000), BASIC SWITCHING RJ-45 ETHERNET PORTS QUANTITY: 24. MAC ADDRESS TABLE: 8000 ENTRIES, SWITCHING CAPACITY: 56 GBIT/S. NETWOR
AC INPUT FREQUENCY, HZ: 50/60
CNCODE: 85176200
CATEGORY CODE: SWI
UNIT BOX HEIGHT: 0.1
UNIT BOX LENGTH: 0.52
UNIT BOX WIDTH: 0.33
ETHERNET LAN DATA RATES, MBIT/S: 10,100,1000
NETWORKING STANDARDS: IEEE 802.1P/IEEE 802.1Q/IEEE 802.1X/IEEE 802.3AB/IEEE 802.3AF/IEEE 802.3AT/IEEE 802.3AZ/IEEE 802.3I/IEEE 802.3U/IEEE 802.3X
PRODUCT COLOUR: BLACK
OPERATING RELATIVE HUMIDITY (H-H), %: 10 - 90
OPERATING TEMPERATURE (T-T), °C: 0 - 50
DEPTH, MM: 234
HEIGHT, MM: 44
WIDTH, MM: 483
COMPLIANCE CERTIFICATES: CB/CE/FEDERAL COMMUNICATIONS COMMISSION (FCC)/INDUSTRY CANADA (IC)/RCM/UKCA
UNITS PER SHIPPING BOX: 1
UNIT CALCULATED VOLUME, CUBM: 0.01716
UNIT CALCULATED WEIGHT, KG: 2.58
MODEL: SWM282
WEIGHT, G: 2291
PACKAGE TYPE: BOX
HOUSING MATERIAL: ALUMINIUM
QUICK START GUIDE: YES
MODEL NAME: SWM282000200
AC INPUT VOLTAGE, V: 100 - 240
QUALITY OF SERVICE (QOS) SUPPORT: YES
SWITCH TYPE: MANAGED
SWITCH LAYER: L2+
BASIC SWITCHING RJ-45 ETHERNET PORTS QUANTITY: 24
BASIC SWITCHING RJ-45 ETHERNET PORTS TYPE: GIGABIT ETHERNET (10/100/1000)
POWER CONNECTOR: AC-IN JACK
10G SUPPORT: NO
PORT MIRRORING: YES
RATE LIMITING: YES
VLAN SUPPORT: YES
FORWARDING RATE, MPPS: 83.33
JUMBO FRAMES SUPPORT: YES
MAC ADDRESS TABLE, ENTRIES: 8000
PACKET BUFFER MEMORY, MB: 0.512
STATIC ROUTE: YES
SWITCHING CAPACITY, GBIT/S: 56
DHCP FEATURES: DHCP CLIENT/DHCP SERVER/DHCPV6 CLIENT
LOOP PROTECTION: YES
RACK MOUNTING: YES
RESET BUTTON: YES
POWER CONSUMPTION (MAX), W: 330
POWER SOURCE: AC
POWER SUPPLY INCLUDED: NO
POWER OVER ETHERNET (POE): YES
POWER OVER ETHERNET (POE) POWER PER PORT, W: 30
POWER OVER ETHERNET (POE) TYPE SUPPORTED: ACTIVE POE/POE+
TOTAL POWER OVER ETHERNET (POE) BUDGET, W: 300
FLASH MEMORY, MB: 16
INTERNAL MEMORY, MB: 128
MEMORY TYPE: DDR3-SDRAM
PROCESSOR FREQUENCY, MHZ: 500
BUILT-IN PROCESSOR: YES
INTERNATIONAL PROTECTION (IP) CODE: IP30
AUTO MDI/MDI-X: YES
AUTHENTICATION TYPE: RADIUS,TACACS+
POWER OVER ETHERNET PLUS (POE+) PORTS QUANTITY: 24
WEB-BASED MANAGEMENT: YES
JUMBO FRAMES: 10000
MAC ADDRESS FILTERING: YES
QUEUE SCHEDULING ALGORITHMS: SP/WEIGHTED ROUND ROBIN (WRR)/WFQ
SFP MODULE SLOTS QUANTITY: 4
FIRMWARE UPGRADEABLE: YES
TRAFFIC SHAPING: YES
POWER OVER ETHERNET (POE) MODES: ALTERNATIVE A
