Mainboard, ASUS, Intel B760 Express, LGA1700, Micro-ATX, Memory DDR4, Memory slots 4, 1xPCI-Express 4.0 16x, 2xM.2, 1xHDMI, 1xD

Mainboard, ASUS, Intel B760 Express, LGA1700, Micro-ATX, Memory DDR4, Memory slots 4, 1xPCI-Express 4.0 16x, 2xM.2, 1xHDMI, 1xD

Name: Mainboard, ASUS, Intel B760 Express, LGA1700, Micro-ATX, Memory DDR4, Memory slots 4, 1xPCI-Express 4.0 16x, 2xM.2, 1xHDMI, 1xD
Brand: ASUS
SKU: PRIME B760M-A D4-CSM
Price: 112.46 EUR
Availability: InStock

Gamintojas: ASUS

Kodas PRIME B760M-A D4-CSM

Yra sandėlyje

112,46 €

Su mokesčiais

Pristatoma 1 - 3 darbo dienos

Intel B760 , micro ATX , Audio 7.1 channels , CPU Intel , Socket LGA 1700 , Series Intel® Celeron®/Intel® Core™ i3/Intel® Core™ i5/Intel® Core™ i7/Intel® Core™ i9/Intel® Pentium® Gold , Supported memory types DDR4-SDRAM , 4xNumber of memory slots , Memory slots type DIMM , Supported storage drive interfaces M.2,SATA III , 4xUSB 2.0 ports quantity , 2xUSB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity , 1xEthernet LAN (RJ-45) ports , 2xHDMI ports quantity

Prekės informacija
Atsiliepimai (0)

SUMMARY: ASUS PRIME B760M-A D4-CSM. PROCESSOR MANUFACTURER: INTEL, PROCESSOR SOCKET: LGA 1700, COMPATIBLE PROCESSOR SERIES: INTEL CELERON , INTEL PENTIUM GOLD, INTEL CORE I3, INTEL CORE I5, INTEL CORE .... SUPPORTED MEMORY TYPES: DDR4-SDRAM, MAXIMUM INTERNAL MEMOR
CATEGORY CODE: MBI
CNCODE: 84733020
UNIT BOX LENGTH: 0.26
UNIT BOX HEIGHT: 0.05
UNIT BOX WIDTH: 0.27
WINDOWS OPERATING SYSTEMS SUPPORTED: WINDOWS 10 X64/WINDOWS 11
DEPTH, MM: 244
WIDTH, MM: 244
MODEL: PRIME B760M-A D4-CSM
UNITS PER SHIPPING BOX: 10
UNIT CALCULATED VOLUME, CUBM: 0.004547
UNIT CALCULATED WEIGHT, KG: 1.15
USB 2.0 PORTS QUANTITY: 4
PARALLEL PROCESSING TECHNOLOGY SUPPORT: NOT SUPPORTED
DISPLAYPORT VERSION: 1.4
DISPLAYPORTS QUANTITY: 1
HDMI PORTS QUANTITY: 2
HDMI VERSION: 2.1
CABLES INCLUDED: SATA
WI-FI: No
ETHERNET LAN: YES
RAID SUPPORT: YES
COMPONENT FOR: PC
COMPATIBLE PROCESSOR SERIES: INTEL CELERON /INTEL CORE I3/INTEL CORE I5/INTEL CORE I7/INTEL CORE I9/INTEL PENTIUM GOLD
SUPPORTED PROCESSOR SOCKETS: LGA 1700
PROCESSOR MANUFACTURER: Intel
PROCESSOR SOCKET: LGA 1700
MEMORY CHANNELS: DUAL-CHANNEL
MAXIMUM INTERNAL MEMORY, GB: 128
AUDIO OUTPUT CHANNELS, CHANNELS: 7.1
MOTHERBOARD CHIPSET: Intel B760
MOTHERBOARD CHIPSET FAMILY: INTEL
MOTHERBOARD FORM FACTOR: MICRO ATX
ECC СOMPATIBILITY: NON-ECC
NUMBER OF MEMORY SLOTS: 4
SUPPORTED MEMORY TYPES: DDR4-SDRAM
UNBUFFERED MEMORY: YES
NUMBER OF STORAGE DRIVES SUPPORTED: 6
RAID LEVELS: 0/1/10/5
SUPPORTED STORAGE DRIVE INTERFACES: M.2,SATA III
SUPPORTED STORAGE DRIVE TYPES: HDD & SSD
12V POWER CONNECTOR: YES
ATX POWER CONNECTOR (24-PIN): YES
CPU FAN CONNECTOR: YES
EPS POWER CONNECTOR (8-PIN): YES
FRONT PANEL AUDIO CONNECTOR: YES
NUMBER OF CHASSIS FAN CONNECTORS: 2
MEMORY SLOTS TYPE: DIMM
RGB LED PIN HEADER: YES
USB 2.0 CONNECTORS: 2
USB 3.2 GEN 1 (3.1 GEN 1) CONNECTORS: 3
ETHERNET LAN (RJ-45) PORTS: 1
NUMBER OF SATA III CONNECTORS: 4
USB 3.2 GEN 2 (3.1 GEN 2) TYPE-A PORTS QUANTITY: 2
ETHERNET INTERFACE TYPE: 2.5 GIGABIT ETHERNET
PS/2 PORTS QUANTITY: 1
NUMBER OF M.2 (M) SLOTS: 2
PCI EXPRESS X16 (GEN 4.X) SLOTS: 3
BIOS MEMORY SIZE, MBIT: 256
BIOS TYPE: UEFI AMI
SUPPORTED MEMORY CLOCK SPEED (MAX), MHZ: 5333
MICROPHONE IN: YES
SUPPORTED MEMORY CLOCK SPEEDS, MHZ: 2133/2400/2666/2800/2933/3000/3200/3333/3400/3466/3600/3733/4000/4266/4400/4600/4800/5000/5066/5333
HEADPHONE OUTPUTS: 3
NUMBER OF COM CONNECTORS: 1
TPM CONNECTOR: YES
S/PDIF OUT CONNECTOR: YES
PCI EXPRESS X1 (GEN 3.X) SLOTS: 1
