Mainboard, ASUS, AMD B850, SAM5, Micro-ATX, Memory DDR5, Memory slots 4, 3xPCI-Express 4.0 16x, 1xPCI-Express 5.0 16x, 3xM.2, 1

Mainboard, ASUS, AMD B850, SAM5, Micro-ATX, Memory DDR5, Memory slots 4, 3xPCI-Express 4.0 16x, 1xPCI-Express 5.0 16x, 3xM.2, 1

Name: Mainboard, ASUS, AMD B850, SAM5, Micro-ATX, Memory DDR5, Memory slots 4, 3xPCI-Express 4.0 16x, 1xPCI-Express 5.0 16x, 3xM.2, 1
Brand: ASUS
SKU: B850M MAX GAMING WIFI
Price: 188.54 EUR
Availability: InStock

Gamintojas: ASUS

Kodas B850M MAX GAMING WIFI

Yra sandėlyje

188,54 €

Su mokesčiais

Pristatoma 1 - 3 darbo dienos

AMD B850 , micro ATX , Audio 7.1 channels , CPU AMD , Socket Socket AM5 , Series AMD Ryzen 7000 Series/AMD Ryzen 8000 Series/AMD Ryzen 9000 Series , Supported memory types DDR5-SDRAM , 4xNumber of memory slots , Memory slots type DIMM , Supported storage drive interfaces M.2,SATA III , 5xUSB 2.0 ports quantity , 2xUSB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity , 1xUSB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity , 1xUSB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity , 1xEthernet LAN (RJ-45) ports , 1xHDMI ports quantity , Wi-Fi Yes , Bluetooth Yes , Antenna included Yes , Weight 859 g

Prekės informacija
Atsiliepimai (0)

SUMMARY: ASUS B850M MAX GAMING WIFI. PROCESSOR MANUFACTURER: AMD, PROCESSOR SOCKET: SOCKET AM5, COMPATIBLE PROCESSOR SERIES: AMD RYZEN 7000 SERIES, AMD RYZEN 8000 SERIES, AMD RYZEN 9000 SERIES. SUPPORTED MEMORY TYPES: DDR5-SDRAM, MAXIMUM INTERNAL MEMORY: 256 GB, M
CATEGORY CODE: MBA
CNCODE: 84733020
UNIT BOX HEIGHT: 0.27
UNIT BOX LENGTH: 0.275
UNIT BOX WIDTH: 0.07
PRODUCT COLOUR: BLACK
DISPLAYPORTS QUANTITY: 1
HDMI PORTS QUANTITY: 1
PACKAGE DEPTH, MM: 275
PACKAGE HEIGHT, MM: 67.5
PACKAGE WEIGHT, G: 1383
PACKAGE WIDTH, MM: 275
CABLES INCLUDED: SATA
MODEL: B850M MAX GAMING WIFI
UNIT CALCULATED VOLUME, CUBM: 0.006259
UNIT CALCULATED WEIGHT, KG: 1.52
MICROPHONE IN: YES
WI-FI: Yes
ETHERNET LAN: YES
USB 2.0 PORTS QUANTITY: 5
BLUETOOTH: YES
BLUETOOTH VERSION: 5.4
WI-FI STANDARDS: WI-FI 6 (802.11AX)
WINDOWS OPERATING SYSTEMS SUPPORTED: WINDOWS 10 X64/WINDOWS 11
ETHERNET LAN (RJ-45) PORTS: 1
USB 3.2 GEN 1 (3.1 GEN 1) TYPE-A PORTS QUANTITY: 2
DEPTH, MM: 244
WEIGHT, G: 859
WIDTH, MM: 244
EPS POWER CONNECTOR (8-PIN): YES
UNITS PER SHIPPING BOX: 10
COOLING TYPE: PASSIVE
SCREWS INCLUDED: YES
ATX POWER CONNECTOR (24-PIN): YES
USB 3.2 GEN 2 (3.1 GEN 2) TYPE-C PORTS QUANTITY: 1
NUMBER OF HDDS SUPPORTED: 4
USB 3.2 GEN 2 (3.1 GEN 2) TYPE-A PORTS QUANTITY: 1
NUMBER OF STORAGE DRIVES SUPPORTED: 7
TOP WI-FI STANDARD: WI-FI 6 (802.11AX)
PROCESSOR MANUFACTURER: AMD
MAXIMUM INTERNAL MEMORY, GB: 256
AUDIO OUTPUT CHANNELS, CHANNELS: 7.1
MOTHERBOARD CHIPSET: AMD B850
LINE-IN: YES
MEMORY CHANNELS: DUAL-CHANNEL
PCI EXPRESS X16 (GEN 5.X) SLOTS: 1
MEMORY SLOTS TYPE: DIMM
PROCESSOR SOCKET: SOCKET AM5
COMPONENT FOR: PC
ETHERNET INTERFACE TYPE: GIGABIT ETHERNET
ANTENNA INCLUDED: YES
PARALLEL PROCESSING TECHNOLOGY SUPPORT: NOT SUPPORTED
RAID SUPPORT: YES
COMPATIBLE PROCESSOR SERIES: AMD RYZEN 7000 SERIES/AMD RYZEN 8000 SERIES/AMD RYZEN 9000 SERIES
SUPPORTED PROCESSOR SOCKETS: SOCKET AM5
MOTHERBOARD CHIPSET FAMILY: AMD
MOTHERBOARD FORM FACTOR: MICRO ATX
ECC СOMPATIBILITY: ECC & NON-ECC
NUMBER OF MEMORY SLOTS: 4
SUPPORTED MEMORY TYPES: DDR5-SDRAM
UNBUFFERED MEMORY: YES
RAID LEVELS: 0/1/10/5
SUPPORTED STORAGE DRIVE INTERFACES: M.2,SATA III
SUPPORTED STORAGE DRIVE TYPES: HDD & SSD
12V POWER CONNECTOR: YES
CPU FAN CONNECTOR: YES
FRONT PANEL AUDIO CONNECTOR: YES
FRONT PANEL CONNECTOR: YES
NUMBER OF CHASSIS FAN CONNECTORS: 4
NUMBER OF SATA III CONNECTORS: 4
RGB LED PIN HEADER: YES
USB 2.0 CONNECTORS: 2
USB 3.2 GEN 1 (3.1 GEN 1) CONNECTORS: 3
WIFI-AP ANTENNA JACK: 1
1ST M.2 HIGHEST PCI EXPRESS GENERATION: 5.0
1ST M.2 LARGEST KEY SIZE: 2280
2ND M.2 HIGHEST PCI EXPRESS GENERATION: 4.0
2ND M.2 LARGEST KEY SIZE: 2280
3RD M.2 HIGHEST PCI EXPRESS GENERATION: 3.0
3RD M.2 LARGEST KEY SIZE: 2280
NUMBER OF M.2 (M) SLOTS: 3
PCI EXPRESS X16 (GEN 4.X) SLOTS: 3
BIOS MEMORY SIZE, MBIT: 256
BIOS TYPE: UEFI AMI
CHASSIS INTRUSION CONNECTOR: YES
NUMBER OF RGB LED PIN HEADERS: 3
TPM CONNECTOR: YES
NUMBER OF COM CONNECTORS: 1
S/PDIF OUT CONNECTOR: YES
